DCEC 60Hz 6ZTAA13 Diesel Generator Set
Sinogen Series diesel generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC 6ZTAA13 series diesel engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 60 Hz of Sinogen Series diesel generator set (1800 RPM) form is 300-350 kW.
Sinogen Series diesel generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of 6ZTAA13 Series
| Engine Type: | 6 Cylinders |
| Displacement(L): | 13 |
| Prime Power(kw): | 300 – 350 |
| Standby Power(kw): | 330 – 380 |
| Engine Speed: |
1800 r/min |
| Generator Frequency: | 60 Hz |
| Bore * Stroke: | 130 mm * 163 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
||
| CDLO300PSOB | 300 kW / 1800 RPM | 6ZTAA13-G3 | CDLO310PSOB | 310 kW / 1800 RPM | 6ZTAA13-G3 | ||
| CDLO330PSOB | 330 kW / 1800 RPM | 6ZTAA13-G2 | CDLO350PSOB-I | 350 kW / 1800 RPM | 6ZTAA13-G2 | ||
| CDLO350PSOB-II | 350 kW / 1800 RPM | 6ZTAA13-G4 | |||||
| ——END—— | |||||||
DCEC 6ZTAA13 Series Diesel Generator Set
This is the list of all series of DCEC 6ZTAA13 Series Diesel Generator Set.
Click here to find 60hz diesel Generator Set by type (Engine Type).
DCEC CDLO350PSOB-II Diesel Generator Set
Genset Model: CDLO350PSOB
Engine Model: 6ZTAA13-G4
Alternator Model：HCI444FS
Rate Power: 350kW / 437.5kVA
Frequency: 60 Hz
DCEC CDLO350PSOB-I Diesel Generator Set
Genset Model: CDLO350PSOB
Engine Model: 6ZTAA13-G2
Alternator Model：HCI444FS
Rate Power: 350kW / 437.5kVA
Frequency: 60 Hz
DCEC CDLO330PSOB Diesel Generator Set
Genset Model: CDLO330PSOB
Engine Model: 6ZTAA13-G2
Alternator Model：HCI444E
Rate Power: 330kW / 412.5kVA
Frequency: 60 Hz
DCEC CDLO310PSOB Diesel Generator Set
Genset Model: CDLO310PSOB
Engine Model: 6ZTAA13-G3
Alternator Model：HCI444ES
Rate Power: 310kW / 387.5kVA
Frequency: 60 Hz
DCEC CDLO300PSOB Diesel Generator Set
Genset Model: CDLO300PSOB
Engine Model: 6ZTAA13-G3
Alternator Model：HCI444ES
Rate Power: 300kW / 375kVA
Frequency: 60 Hz
