DCEC 60Hz 6CTA8.3 Diesel Genertor Set
Sinogen Series diesel generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC 6CTA8.3 series diesel engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 60 Hz of Sinogen Series diesel generator set (1800 RPM) form is 134-180 kW.
Sinogen Series diesel generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of 6CTA8.3 Series
| Engine Type: | 6 Cylinders,in Line |
| Displacement(L): | 8.3 |
| Prime Power(kw): | 134 – 180 |
| Standby Power(kw): | 148 – 200 |
| Engine Speed: |
1800 r/min |
| Generator Frequency: | 60 Hz |
| Bore * Stroke: | 114 mm * 135 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
||
| CDLO134PSOB | 134 kW / 1800 RPM | 6CTA8.3-G2 | CDLO150PSOB | 150 kW / 1800 RPM | 6CTA8.3-G2 | ||
| CDLO160PSOB | 160 kW / 1800 RPM | 6CTA8.3-G2 | CDLO168PSOB | 168 kW / 1800 RPM | 6CTAA8.3-G2 | ||
| CDLO180PSOB | 180 kW / 1800 RPM | 6CTAA8.3-G2 | |||||
| ——END—— | |||||||
DCEC 6CTA8.3 Series Diesel Genertor Set
This is the list of all series of DCEC 6CTA8.3 Series Diesel Genertor Set.
Click here to find 60hz diesel Generator Set by type (Engine Type).
DCEC CDLO180PSOB Diesel Generator Set
Genset Model: CDLO180PSOB
Engine Model: 6CTAA8.3-G2
Alternator Model：UCI274H
Rate Power: 180kW / 225kVA
Frequency: 60 Hz
DCEC CDLO168PSOB Diesel Generator Set
Genset Model: CDLO168PSOB
Engine Model: 6CTAA8.3-G2
Alternator Model：UCI274G
Rate Power: 168kW / 210kVA
Frequency: 60 Hz
DCEC CDLO160PSOB Diesel Generator Set
Genset Model: CDLO160PSOB
Engine Model: 6CTA8.3-G2
Alternator Model：UCI274G
Rate Power: 160kW / 200kVA
Frequency: 60 Hz
DCEC CDLO150PSOB Diesel Generator Set
Genset Model: CDLO150PSOB
Engine Model: 6CTA8.3-G2
Alternator Model：UCI274F
Rate Power: 150kW / 187.5kVA
Frequency: 60 Hz
DCEC CDLO134PSOB Diesel Generator Set
Genset Model: CDLO134PSOB
Engine Model: 6CTA8.3-G2
Alternator Model：UCI274E
Rate Power: 134kW / 168kVA
Frequency: 60 Hz
