DCEC 60Hz 6BT5.9 Diesel Generator Set
Sinogen Series diesel generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC 6BT5.9 series diesel engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 60 Hz of Sinogen Series diesel generator set (1800 RPM) form is 78-128 kW.
Sinogen Series diesel generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of 6BT5.9 Series
| Engine Type: | 6 Cylinders |
| Displacement(L): | 5.9 |
| Prime Power(kw): | 78 – 128 |
| Standby Power(kw): | 86 – 140 |
| Engine Speed: |
1800 r/min |
| Generator Frequency: | 60 Hz |
| Bore * Stroke: | 102 mm * 120 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
|||
| CDLO78PSOB | 78 kW / 1800 RPM | 6BT5.9-G2 | CDLO84PSOB | 84 kW / 1800 RPM | 6BT5.9-G2 | |||
| CDLO88PSOB | 88 kW / 1800 RPM | 6BT5.9-G2 | CDLO100PSOB | 100 kW / 1800 RPM | 6BT5.9-G2 | |||
| CDLO105PSOB | 105 kW / 1800 RPM | 6BTA5.9-G2 | CDLO118PSOB | 118 kW / 1800 RPM | 6BTAA5.9-G2 | |||
| CDLO128PSOB | 128 kW / 1800 RPM | 6BTAA5.9-G12 | ||||||
| ——END—— | ||||||||
DCEC 6BT5.9 Series Diesel Generator Set
This is the list of all series of DCEC 6BT5.9 Series Diesel Generator Set.
Click here to find 60hz diesel Generator Set by type (Engine Type).
DCEC CDLO128PSOB Diesel Generator Set
Genset Model: CDLO128PSOB
Engine Model: 6BTAA5.9-G12
Alternator Model：UCI274E
Rate Power: 128kW / 160kVA
Frequency: 60 Hz
DCEC CDLO118PSOB Diesel Generator Set
Genset Model: CDLO118PSOB
Engine Model: 6BTAA5.9-G2
Alternator Model：UCI274E
Rate Power: 118kW / 147.5kVA
Frequency: 60 Hz
DCEC CDLO105PSOB Diesel Generator Set
Genset Model: CDLO105PSOB
Engine Model: 6BTA5.9-G2
Alternator Model：UCI274D
Rate Power: 105kW / 131.25kVA
Frequency: 60 Hz
DCEC CDLO100PSOB Diesel Generator Set
Genset Model: CDLO100PSOB
Engine Model: 6BT5.9-G2
Alternator Model：UCI274D
Rate Power: 100kW / 125kVA
Frequency: 60 Hz
DCEC CDLO88PSOB Diesel Generator Set
Genset Model: CDLO88PSOB
Engine Model: 6BT5.9-G2
Alternator Model：UCI274C
Rate Power: 88kW / 110kVA
Frequency: 60 Hz
DCEC CDLO84PSOB Diesel Generator Set
Genset Model: CDLO84PSOB
Engine Model: 6BT59-G2
Alternator Model：UCI274C
Rate Power: 84kW / 105kVA
Frequency: 60 Hz
DCEC CDLO78PSOB Diesel Generator Set
Genset Model: CDLO78PSOB
Engine Model: 6BT5.9-G2
Alternator Model：UCI224G
Rate Power: 78kW / 97.5kVA
Frequency: 60 Hz
