DCEC 60Hz 4BT3.9 Diesel Generator Set
Sinogen Series diesel generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC 4BT3.9 series diesel engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 60 Hz of Sinogen Series diesel generator set (1800 RPM) form is 18-70 kW.
Sinogen Series diesel generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of 4BT3.9 Series
| Engine Type: | 4 Cylinders |
| Displacement(L): | 3.9 |
| Prime Power(kw): | 18 – 70 |
| Standby Power(kw): | 20 – 76 |
| Engine Speed: |
1800 r/min |
| Generator Frequency: | 60 Hz |
| Bore * Stroke: | 102 mm * 120 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
||
| CDLO18PSOB | 18 kW / 1800 RPM | 4B3.9-G11 | CDLO20PSOB | 20 kW / 1800 RPM | 4B3.9-G11 | ||
| CDLO25PSOB | 25 kW / 1800 RPM | 4B3.9-G12 | CDLO27.2PSOB | 27.2 kW / 1800 RPM | 4B3.9-G12 | ||
| CDLO24PSOB | 24 kW / 1800 RPM | 4B3.9-G2 | CDLO33PSOB | 33 kW / 1800 RPM | 4BT3.9-G2 | ||
| CDLO40PSOB | 40 kW / 1800 RPM | 4BT3.9-G2 | CDLO42PSOB | 42 kW / 1800 RPM | 4BTA3.9-G2 | ||
| CDLO50PSOB | 50 kW / 1800 RPM | 4BTA3.9-G2 | CDLO54PSOB-I | 54 kW / 1800 RPM | 4BTA3.9-G2 | ||
| CDLO60PSOB | 60 kW / 1800 RPM | 4BTA3.9-G2 | CDLO54PSOB-II | 54 kW / 1800 RPM | 4BTA3.9-G11 | ||
| CDLO70PSOB | 70 kW / 1800 RPM | 4BTA3.9-G11 | |||||
| ——END—— | |||||||
DCEC 4BT3.9 Series Diesel Generator Set
This is the list of all series of DCEC 4BT3.9 Series Diesel Generator Set.
Click here to find 60hz diesel Generator Set by type (Engine Type).
DCEC CDLO70PSOB Diesel Generator Set
Genset Model: CDLO70PSOB
Engine Model: 4BTA3.9-G11
Alternator Model：UCI224F
Rate Power: 70kW / 87.5kVA
Frequency: 60 Hz
DCEC CDLO54PSOB-II Diesel Generator Set
Genset Model: CDLO54PSOB
Engine Model: 4BTA3.9-G11
Alternator Model：UCI224E
Rate Power: 54kW / 67.5kVA
Frequency: 60 Hz
DCEC CDLO60PSOB Diesel Generator Set
Genset Model: CDLO60PSOB
Engine Model: 4BTA3.9-G2
Alternator Model：UCI224F
Rate Power: 60kW / 75kVA
Frequency: 60 Hz
DCEC CDLO54PSOB-I Diesel Generator Set
Genset Model: CDLO54PSOB
Engine Model: 4BTA3.9-G2
Alternator Model：UCI224E
Rate Power: 54kW / 67.5kVA
Frequency: 60 Hz
DCEC CDLO50PSOB Diesel Generator Set
Genset Model: CDLO50PSOB
Engine Model: 4BTA3.9-G2
Alternator Model：UCI224D
Rate Power: 50kW / 62.5kVA
Frequency: 60 Hz
DCEC CDLO42PSOB Diesel Generator Set
Genset Model: CDLO42PSOB
Engine Model: 4BTA3.9-G2
Alternator Model：PI144K
Rate Power: 42kW / 52.5kVA
Frequency: 60 Hz
DCEC CDLO40PSOB Diesel Generator Set
Genset Model: CDLO40PSOB
Engine Model: 4BT3.9-G2
Alternator Model：PI144K
Rate Power: 40kW / 50kVA
Frequency: 60 Hz
DCEC CDLO33PSOB Diesel Generator Set
Genset Model: CDLO33PSOB
Engine Model: 4BT3.9-G2
Alternator Model：PI144J
Rate Power: 33kW / 41.25kVA
Frequency: 60 Hz
DCEC CDLO24PSOB Diesel Generator Set
Genset Model: CDLO24PSOB
Engine Model: 4B3.9-G2
Alternator Model：PI144F
Rate Power: 24kW / 30kVA
Frequency: 60 Hz
DCEC CDLO27.2PSOB Diesel Generator Set
Genset Model: CDLO27.2PSOB
Engine Model: 4B3.9-G12
Alternator Model：PI144G
Rate Power: 27.2kW / 34kVA
Frequency: 60 Hz
DCEC CDLO25PSOB Diesel Generator Set
Genset Model: CDLO25PSOB
Engine Model: 4B3.9-G12
Alternator Model：PI144F
Rate Power: 25kW / 31kVA
Frequency: 60 Hz
DCEC CDLO20PSOB Diesel Generator Set
Genset Model: CDLO20PSOB
Engine Model: 4B3.9-G11
Alternator Model：PI144E
Rate Power: 20kW / 25kVA
Frequency: 60 Hz
DCEC CDLO18PSOB Diesel Generator Set
Genset Model: CDLO18PSOB
Engine Model: 4B3.9-G11
Alternator Model：PI144D
Rate Power: 18kW / 22.5kVA
Frequency: 60 Hz
