DCEC 60Hz 6CTA8.3 Marine Auxiliary Generator Set
Sinogen Series marine generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC 6CTA8.3-GM series marine engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 60 Hz of Sinogen Series marine generator set (1800 RPM) form is 110-150 kW.
Sinogen Series marine generator set supports low noise generator set and chassis fuel tank, each marine generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of 6CTA8.3-GM Series
| Engine Type: | In-Line,6 Cylinders |
| Displacement(L): | 8.3 |
| Prime Power(kw): | 110 – 150 |
| Standby Power(kw): | 142 – 193 |
| Engine Speed: |
1800 r/min |
| Generator Frequency: | 60 Hz |
| Bore * Stroke: | 114 mm * 135 mm |
| Weight: | 1500 kg |
| Dimension(L * W * H): | 2210 mm * 860 mm * 1360 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
||||
| CDMO110PSOB | 129 kW / 161.25 kVA | 6CT8.3-GM129 | CDMO120PSOB | 175 kW / 218.75 kVA | 6CTA8.3-GM175 | ||||
| CDMO150PSOB | 175 kW / 218.75 kVA | 6CTA8.3-GM175 | CCFJ110J-W | 110 kW | 6CT8.3-GM129 | ||||
| CCFJ120J-W | 120 kW | 6CTA8.3-GM175 | CCFJ150J-W | 150 kW | 6CTA8.3-GM175 | ||||
| ——END—— | |||||||||
DCEC 6CTA8.3 Series Marine Auxiliary Generator Set
This is the list of all series of DCEC 6CTA8.3 Series Marine Auxiliary Generator Set.
Click here to find 60hz Marine Auxiliary Generator Set by type (Engine Type).
DCEC CCFJ150J-W Marine Auxiliary Generator Set
Genset Model: CCFJ150J-W
Engine Model: 6CTA8.3-GM175
Alternator Model：UCM 274G
Rate Power: 150kW / 187.5kVA
Frequency: 60 Hz
DCEC CCFJ120J-W Marine Auxiliary Generator Set
Genset Model: CCFJ120J-W
Engine Model: 6CTA8.3-GM175
Alternator Model：UCM 274F
Rate Power: 120kW / 150kVA
Frequency: 60 Hz
DCEC CCFJ110J-W Marine Auxiliary Generator Set
Genset Model: CCFJ110J-W
Engine Model: 6CT8.3-GM129
Alternator Model：UCM 274E
Rate Power: 110kW / 137.5kVA
Frequency: 60 Hz
DCEC 60Hz CDMO110PSOB Marine Auxiliary Generator Set
Prime Power: 129 kW / 161.25 kVA
Standby Power: 142 kW / 177.5 kVA
Engine Model: 6CT8.3-GM129
Engine Speed: 1800 RPM
Frequency: 60 Hz
DCEC 60Hz CDMO120PSOB Marine Auxiliary Generator Set
Prime Power: 175 kW / 218.75 kVA
Standby Power: 193 kW / 241.25 kVA
Engine Model: 6CTA8.3-GM175
Engine Speed: 1800 RPM
Frequency: 60 Hz
DCEC 60Hz CDMO150PSOB Marine Auxiliary Generator Set
Prime Power: 175 kW / 218.75 kVA
Standby Power: 193 kW / 241.25 kVA
Engine Model: 6CTA8.3-GM175
Engine Speed: 1800 RPM
Frequency: 60 Hz
