DCEC 60Hz 6BT5.9 Marine Auxiliary Generator Set
Sinogen Series marine generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC 6BT5.9-GM series marine engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 60 Hz of Sinogen Series marine generator set (1800 RPM) form is 64-100 kW.
Sinogen Series marine generator set supports low noise generator set and chassis fuel tank, each marine generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of 6BT5.9-GM Series
| Engine Type: | In-Line,6 Cylinders |
| Displacement(L): | 5.9 |
| Prime Power(kw): | 64 – 100 |
| Standby Power(kw): | 110 – 132 |
| Engine Speed: |
1800 r/min |
| Generator Frequency: | 60 Hz |
| Bore * Stroke: | 102 mm * 120 mm |
| Wet Weight: | 1000 – 1250 kg |
| Dimension(L * W * H): | 1905 mm * 895 mm * 1300 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
|||
| CDMO64PSOB | 100 kW / 125 kVA | 6BT5.9-GM100 | CDMO75PSOB | 100 kW / 125 kVA | 6BT5.9-GM100 | |||
| CDMO80PSOB | 100 kW / 125 kVA | 6BT5.9-GM100 | CDMO90PSOB | 120 kW / 156.25 kVA | 6BT5.9-GM120 | |||
| CDMO100PSOB | 120 kW / 156.25 kVA | 6BT5.9-GM120 | CCFJ64J-W | 64 kW | 6BT5.9-GM100 | |||
| CCFJ75J-W | 75 kW | 6BT5.9-GM100 | CCFJ80J-W | 80 kW | 6BT5.9-GM100 | |||
| CCFJ90J-W | 90 kW | 6BT5.9-GM120 | CCFJ100J-W | 100 kW | 6BT5.9-GM120 | |||
| ——END—— | ||||||||
DCEC 6BT5.9 Series Marine Auxiliary Generator Set
This is the list of all series of DCEC 6BT5.9 Series Marine Auxiliary Generator Set.
Click here to find 60hz Marine Auxiliary Generator Set by type (Engine Type).
DCEC CCFJ100J-W Marine Auxiliary Generator Set
Genset Model: CCFJ100J-W
Engine Model: 6BT5.9-GM120
Alternator Model：UCM 274E
Rate Power: 100kW / 125kVA
Frequency: 60 Hz
DCEC CCFJ90J-W Marine Auxiliary Generator Set
Genset Model: CCFJ90J-W
Engine Model: 6BT5.9-GM120
Alternator Model：UCM 274D
Rate Power: 90kW / 112.5kVA
Frequency: 60 Hz
DCEC CCFJ80J-W Marine Auxiliary Generator Set
Genset Model: CCFJ80J-W
Engine Model: 6BT5.9-GM100
Alternator Model：UCM 274D
Rate Power: 80kW / 100kVA
Frequency: 60 Hz
DCEC CCFJ75J-W Marine Auxiliary Generator Set
Genset Model: CCFJ75J-W
Engine Model: 6BT5.9-GM100
Alternator Model：UCM 274C
Rate Power: 75kW / 93.75kVA
Frequency: 60 Hz
DCEC CCFJ64J-W Marine Auxiliary Generator Set
Genset Model: CCFJ64J-W
Engine Model: 6BT5.9-GM100
Alternator Model：UCM 224G
Rate Power: 64kW / 80kVA
Frequency: 50 Hz
DCEC 60Hz CDMO64PSOB Marine Auxiliary Generator Set
Prime Power: 100 kW / 125 kVA
Standby Power: 110 kW / 147.5 kVA
Engine Model: 6BT5.9-GM100
Engine Speed: 1800 RPM
Frequency: 60 Hz
DCEC 60Hz CDMO75PSOB Marine Auxiliary Generator Set
Prime Power: 100 kW / 125 kVA
Standby Power: 110 kW / 147.5 kVA
Engine Model: 6BT5.9-GM100
Engine Speed: 1800 RPM
Frequency: 60 Hz
DCEC 60Hz CDMO80PSOB Marine Auxiliary Generator Set
Prime Power: 100 kW / 125 kVA
Standby Power: 110 kW / 147.5 kVA
Engine Model: 6BT5.9-GM100
Engine Speed: 1800 RPM
Frequency: 60 Hz
DCEC 60Hz CDMO90PSOB Marine Auxiliary Generator Set
Prime Power: 120 kW / 156.25 kVA
Standby Power: 132 kW / 171.87 kVA
Engine Model: 6BT5.9-GM120
Engine Speed: 1800 RPM
Frequency: 60 Hz
DCEC 60Hz CDMO100PSOB Marine Auxiliary Generator Set
Prime Power: 120 kW / 156.25 kVA
Standby Power: 132 kW / 171.87 kVA
Engine Model: 6BT5.9-GM120
Engine Speed: 1800 RPM
Frequency: 60 Hz
