DCEC 50Hz QSB6.7 Diesel Genertor Set
Sinogen Series diesel generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC QSB6.7 series diesel engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 50 Hz of Sinogen Series diesel generator set (1500 RPM) form is 120-145.6 kW.
Sinogen Series diesel generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of QSB6.7 Series
| Engine Type: | 6 Cylinders |
| Displacement(L): | 6.7 |
| Prime Power(kw): | 120 – 145.6 |
| Standby Power(kw): | 132 – 160 |
| Engine Speed: |
1500 r/min |
| Generator Frequency: | 50 Hz |
| Bore * Stroke: | 107 mm * 124 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
|||
| CDLO120PSOA | 120 kW / 1500 RPM | QSB6.7-G3 | CDLO145.6PSOA | 145.6 kW / 1500 RPM | QSB6.7-G4 | |||
| ——END—— | ||||||||
DCEC QSB6.7 Series Diesel Genertor Set
This is the list of all series of DCEC QSB6.7 Series Diesel Genertor Set .
Click here to find 50hz diesel Generator Set by type (Engine Type).
DCEC CDLO145.6PSOA Diesel Generator Set
Genset Model: CDLO145.6PSOA
Engine Model: QSB6.7-G4
Alternator Model：UCI274G
Rate Power: 145.6kW / 182kVA
Frequency: 50 Hz
DCEC CDLO120PSOA Diesel Generator Set
Genset Model: CDLO120PSOA
Engine Model: QSB6.7-G3
Alternator Model：UCI274F
Rate Power: 120kW / 150kVA
Frequency: 50 Hz
