DCEC 50Hz QSB5.9 Diesel Genertor Set
Sinogen Series diesel generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC QSB5.9 series diesel engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 50 Hz of Sinogen Series diesel generator set (1500 RPM) form is 80-100 kW.
Sinogen Series diesel generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of QSB5.9 Series
| Engine Type: | 6 Cylinders |
| Displacement(L): | 5.9 |
| Prime Power(kw): | 80 – 100 |
| Standby Power(kw): | 88 – 110 |
| Engine Speed: |
1500 r/min |
| Generator Frequency: | 50 Hz |
| Bore * Stroke: | 102 mm * 120 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
|||
| CDLO80PSOA | 80 kW / 1500 RPM | QSB5.9-G2 | CDLO100PSOA | 100 kW / 1500 RPM | QSB5.9-G3 | |||
| ——END—— | ||||||||
DCEC QSB5.9 Series Diesel Genertor Set
This is the list of all series of DCEC QSB5.9 Series Diesel Genertor Set.
Click here to find 50hz diesel Genertor Set by type (Engine Type).
DCEC CDLO100PSOA Diesel Generator Set
Genset Model: CDLO100PSOA
Engine Model: QSB5.9-G3
Alternator Model：UCI274ES
Rate Power: 100kW / 125kVA
Frequency: 50 Hz
DCEC CDLO80PSOA Diesel Generator Set
Genset Model: CDLO80PSOA
Engine Model: QSB5.9-G2
Alternator Model：UCI274C
Rate Power: 80kW / 100kVA
Frequency: 50 Hz
