DCEC 50Hz 6LTAA9.5 Diesel Generator Set
Sinogen Series diesel generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC 6LTAA9.5 series diesel engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 50 Hz of Sinogen Series diesel generator set (1500 RPM) form is 220-260 kW.
Sinogen Series diesel generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of 6LTAA9.5 Series
| Engine Type: | In-Line,6 Cylinders |
| Displacement(L): | 9.5 |
| Prime Power(kw): | 220 – 260 |
| Standby Power(kw): | 240 – 284 |
| Engine Speed: |
1500 r/min |
| Generator Frequency: | 50 Hz |
| Bore * Stroke: | 114 mm * 145 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
|||
| CDLO220PSOA | 220 kW / 1500 RPM | 6LTAA9.5-G3 | CDLO240PSOA | 240 kW / 1500 RPM | 6LTAA9.5-G1 | |||
| CDLO260PSOA | 260 kW / 1500 RPM | 6LTAA9.5-G1 | ||||||
| ——END—— | ||||||||
DCEC 6LTAA9.5 Series Diesel Generator Set
This is the list of all series of DCEC 6LTAA9.5 Series Diesel Generator Set.
Click here to find 50hz diesel Generator Set by type (Engine Type).
DCEC CDLO260PSOA Diesel Generator Set Video
Genset Model: CDLO260PSOA
Engine Model: 6LTAA9.5-G1
Alternator Model：HCI444ES
Rate Power: 260kW / 325kVA
Frequency: 50 Hz
DCEC CDLO240PSOA Diesel Generator Set Video
Genset Model: CDLO240PSOA
Engine Model: 6LTAA9.5-G1
Alternator Model：HCI444D
Rate Power: 240kW / 300kVA
Frequency: 50 Hz
DCEC CDLO220PSOA Diesel Generator Set
Genset Model: CDLO220PSOA
Engine Model: 6LTAA9.5-G3
Alternator Model：HCI444D
Rate Power: 220kW / 275kVA
Frequency: 50 Hz
