DCEC 50Hz 6LTAA8.9 Marine Main Genertor Set
Sinogen Series marine generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC 6LTAA8.9-M series marine engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 50 Hz of Sinogen Series marine generator set (1500 RPM) form is 150-180 kW.
Sinogen Series marine generator set supports low noise generator set and chassis fuel tank, each marine generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of 6LTAA8.9-M Series
| Engine Type: | In-Line,6 Cylinders |
| Displacement(L): | 8.9 |
| Prime Power(kw): | 150 – 180 |
| Standby Power(kw): | 220 |
| Engine Speed: |
1500 r/min |
| Generator Frequency: | 50 Hz |
| Bore * Stroke: | 114 mm * 135 mm |
| Weight: | 1800 – 1850 kg |
| Dimension(L * W * H): | 2226 mm * 860 mm * 1670 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
||
| CDMO150PSOA | 200kW/250kVA | DCEC 6LTAA8.9-GM200 | CDMO180PSOA | 200kW/250kVA | DCEC 6LTAA8.9-GM200 | ||
| ——END—— | |||||||
DCEC 6LTAA8.9 Series Marine Main Genertor Set
This is the list of all series of DCEC 6LTAA8.9 Series Marine Main Genertor Set.
Click here to find 50hz Marine Main Generator by type (Engine Type).
DCEC CDMO150PSOA Marine Main Generator Set
Prime Power：200 kW / 250 kVA
Standby Power: 220 kW / 275 kVA
Engine Model：DCEC 6LTAA8.9-GM200
Engine Speed: 1500 RPM
Frequency: 50 Hz
DCEC CDMO180PSOA Marine Main Generator Set
Prime Power：200 kW / 250 kVA
Standby Power: 220 kW / 275 kVA
Engine Model：DCEC 6LTAA8.9-GM200
Engine Speed: 1500 RPM
Frequency: 50 Hz
