DCEC 50Hz 6LTAA8.9 Diesel Genertor Set
Sinogen Series diesel generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC 6LTAA8.9 series diesel engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 50 Hz of Sinogen Series diesel generator set (1500 RPM) form is 180-260 kW.
Sinogen Series diesel generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of 6LTAA8.9 Series
| Engine Type: | In-Line,6 Cylinders |
| Displacement(L): | 8.9 |
| Prime Power(kw): | 180 – 200 |
| Standby Power(kw): | 200 – 240 |
| Engine Speed: |
1500 r/min |
| Generator Frequency: | 50 Hz |
| Bore * Stroke: | 114 mm * 135 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
|||
| CDLO180PSOA | 220 kW / 1500 RPM | 6LTAA8.9-G2 | CDLO182PSOA | 182 kW / 1500 RPM | 6LTAA8.9-G2 | |||
| CDLO200PSOA | 200 kW / 1500 RPM | 6LTAA8.9-G3 | ||||||
| ——END—— | ||||||||
DCEC 6LTAA8.9 Series Diesel Genertor Set
This is the list of all series of DCEC 6LTAA8.9 Series Diesel Genertor Set.
Click here to find 50hz diesel Generator Set by type (Engine Type).
DCEC CDLO200PSOA Diesel Generator Set
Genset Model: CDLO200PSOA
Engine Model: 6LTAA8.9-G3
Alternator Model：UCDI274K
Rate Power: 200kW / 250kVA
Frequency: 50 Hz
DCEC CDLO182PSOA Diesel Generator Set
Genset Model: CDLO182PSOA
Engine Model: 6LTAA8.9-G2
Alternator Model：UCDI274J
Rate Power: 182kW / 227.5kVA
Frequency: 50 Hz
DCEC 50Hz CDLO180PSOA Industrial Generator Set
Prime Power：220 kW/ 1500 RPM
Engine Model：6LTAA8.9-G2
Engine Rated Power: 180 kW
Alternator Brand：Stamford
Alternator Model：UCD274K
