DCEC 50Hz 6CTA8.3 Diesel Genertor Set
Sinogen Series diesel generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC 6CTA8.3 series diesel engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 50 Hz of Sinogen Series diesel generator set (1500 RPM) form is 128-165 kW.
Sinogen Series diesel generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of 6CTA8.3 Series
| Engine Type: | In-Line,6 Cylinders |
| Displacement(L): | 8.3 |
| Prime Power(kw): | 128 – 165 |
| Standby Power(kw): | 179 – 201 |
| Engine Speed: |
1500 r/min |
| Generator Frequency: | 50 Hz |
| Bore * Stroke: | 114 mm * 135 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
||
| CDLO150PSOA | 163 kW / 1500 RPM | 6CTA8.3-G1 | CDLO165PSOA | 183 kW / 1500 RPM | 6CTAA8.3-G2 | ||
| CDLO128PSOA-I | 128 kW / 1500 RPM | 6CTA8.3-G1 | CDLO128PSOA-II | 128 kW / 1500 RPM | 6CTA8.3-G2 | ||
| CDLO145.6PSOA-I | 145.6 kW / 1500 RPM | 6CTA8.3-G1 | CDLO145.6PSOA-II | 145.6 kW / 1500 RPM | 6CTA8.3-G2 | ||
| CDLO160PSOA | 160 kW / 1500 RPM | 6CTAA8.3-G2 | |||||
| ——END—— | |||||||
DCEC 6CTA8.3 Series Diesel Genertor Set
This is the list of all series of DCEC 6CTA8.3 Series Diesel Genertor Set.
Click here to find 50hz diesel Generator Set by type (Engine Type).
DCEC CDLO160PSOA Diesel Generator Set
Genset Model: CDLO160PSOA
Engine Model: 6CTAA8.3-G2
Alternator Model：UCI274H
Rate Power: 160kW / 200kVA
Frequency: 50 Hz
DCEC CDLO145.6PSOA-II Diesel Generator Set
Genset Model: CDLO145.6PSOA
Engine Model: 6CTA8.3-G2
Alternator Model：UCI274G
Rate Power: 145.6kW / 182kVA
Frequency: 50 Hz
DCEC CDLO145.6PSOA-I Diesel Generator Set
Genset Model: CDLO145.6PSOA
Engine Model: 6CTA8.3-G1
Alternator Model：UCI274G
Rate Power: 145.6kW / 182kVA
Frequency: 50 Hz
DCEC CDLO128PSOA-II Diesel Generator Set
Genset Model: CDLO128PSOA
Engine Model: 6CTA8.3-G2
Alternator Model：UCI274F
Rate Power: 128kW / 160kVA
Frequency: 50 Hz
DCEC CDLO128PSOA-I Diesel Generator Set
Genset Model: CDLO128PSOA
Engine Model: 6CTA8.3-G1
Alternator Model：UCI274F
Rate Power: 128kW / 160kVA
Frequency: 50 Hz
DCEC 50Hz CDLO150PSOA Industrial Generator Set
Prime Power：163 kW / 1500 RPM
Engine Model：6CTA8.3-G1
Engine Rated Power: 150 kW
Alternator Brand：Stamford
Alternator Model：UCI274H
DCEC 50Hz CDLO165PSOA Industrial Generator Set
Prime Power：183 kW / 1500 RPM
Engine Model：6CTAA8.3-G2
Engine Rated Power: 165 kW
Alternator Brand：Stamford
Alternator Model：UCI274H
