DCEC 50Hz 6BT5.9 Marine Auxiliary Genertor Set
Sinogen Series marine generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC 6BT5.9-GM series marine engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 50 Hz of Sinogen Series marine generator set (1500 RPM) form is 83-100 kW.
Sinogen Series marine generator set supports low noise generator set and chassis fuel tank, each marine generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of 6BT5.9-GM Series
| Engine Type: | In-Line,6 Cylinders |
| Displacement(L): | 5.9 |
| Prime Power(kw): | 83 – 100 |
| Standby Power(kw): | N/A |
| Engine Speed: |
1500 r/min |
| Generator Frequency: | 50 Hz |
| Bore * Stroke: | 102 mm * 120 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
||||
| CCFJ50J-W | 50 kW | 6BT5.9-GM83 | CCFJ60J-W | 60 kW | 6BT5.9-GM83 | ||||
| CCFJ64J-W | 64 kW | 6BT5.9-GM83 | CCFJ70J-W | 70 kW | 6BT5.9-GM83 | ||||
| CCFJ75J-W | 75 kW | 6BT5.9-GM83 | CCFJ80J-W | 80 kW | 6BTA5.9-GM100 | ||||
| CCFJ90J-W | 90 kW | 6BTA5.9-GM100 | |||||||
| ——END—— | |||||||||
DCEC 6BT5.9 Series Marine Auxiliary Generator Set
This is the list of all series of DCEC 6BT5.9 Series Marine Auxiliary Generator Set.
Click here to find 50hz Marine Auxiliary Generator by type (Engine Type).
DCEC CCFJ90J-W Marine Auxiliary Generator Set
Genset Model: CCFJ90J-W
Engine Model: 6BTA5.9-GM100
Alternator Model：UCM 274E
Rate Power: 90kW / 112.5kVA
Frequency: 50 Hz
DCEC CCFJ80J-W Marine Auxiliary Generator Set
Genset Model: CCFJ80J-W
Engine Model: 6BTA5.9-GM100
Alternator Model：UCM 274D
Rate Power: 80kW / 100kVA
Frequency: 50 Hz
DCEC CCFJ75J-W Marine Auxiliary Generator Set
Genset Model: CCFJ75J-W
Engine Model: 6BT5.9-GM83
Alternator Model：UCM 274D
Rate Power: 75kW / 93.75kVA
Frequency: 50 Hz
DCEC CCFJ70J-W Marine Auxiliary Generator Set
Genset Model: CCFJ70J-W
Engine Model: 6BT5.9-GM83
Alternator Model：UCM 274D
Rate Power: 70kW / 87.5kVA
Frequency: 50 Hz
DCEC CCFJ64J-W Marine Auxiliary Generator Set
Genset Model: CCFJ64J-W
Engine Model: 6BT5.9-GM83
Alternator Model：UCM 274C
Rate Power: 54kW / 80kVA
Frequency: 50 Hz
DCEC CCFJ60J-W Marine Auxiliary Generator Set
Genset Model: CCFJ60J-W
Engine Model: 6BT5.9-GM83
Alternator Model：UCM 224G
Rate Power: 60kW / 75kVA
Frequency: 50 Hz
DCEC CCFJ50J-W Marine Auxiliary Generator Set
Genset Model: CCFJ50J-W
Engine Model: 6BT5.9-GM83
Alternator Model：UCM 224F
Rate Power: 50kW / 62.5kVA
Frequency: 50 Hz
