DCEC 50Hz 6BT5.9 Diesel Genertor Set
Sinogen Series diesel generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC 6BT5.9 series diesel engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 50 Hz of Sinogen Series diesel generator set (1500 RPM) form is 50-120 kW.
Sinogen Series diesel generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of 6BT5.9 Series
| Engine Type: | In-Line,6 Cylinders |
| Displacement(L): | 5.9 |
| Prime Power(kw): | 50 – 120 |
| Standby Power(kw): | 75 – 132 |
| Engine Speed: |
1500 r/min |
| Generator Frequency: | 50 Hz |
| Bore * Stroke: | 102 mm * 120 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
||
| CDLO50PSOA | 92 kW / 1500 RPM | 6BT5.9-G1 | CDLO75PSOA | 90 kW / 1500 RPM | 6BT5.9-G2 | ||
| CDLO100PSOA-I | 100 kW / 1500 RPM | 6BTA5.9-G2 | CDLO68PSOA-I | 68 kW / 1500 RPM | 6BT5.9-G1 | ||
| CDLO72PSOA-I | 72 kW / 1500 RPM | 6BT5.9-G1 | CDLO80PSOA-I | 80 kW / 1500 RPM | 6BT5.9-G1 | ||
| CDLO68PSOA-II | 68 kW / 1500 RPM | 6BT5.9-G2 | CDLO72PSOA-II | 72 kW / 1500 RPM | 6BT5.9-G2 | ||
| CDLO80PSOA-II | 80 kW / 1500 RPM | 6BT5.9-G2 | CDLO80PSOA-III | 80 kW / 1500 RPM | 6BT5.9-G2 | ||
| CDLO90PSOA | 90 kW / 1500 RPM | 6BTA5.9-G2 | CDLO100PSOA-II | 100 kW / 1500 RPM | 6BTAA5.9-G2 | ||
| CDLO110PSOA | 110 kW / 1500 RPM | 6BTAA5.9-G2 | CDLO120PSOA | 120 kW / 1500 RPM | 6BTAA5.9-G12 | ||
| ——END—— | |||||||
DCEC 6BT5.9 Series Diesel Genertor Set
This is the list of all series of DCEC 6BT5.9 Series Diesel Genertor Set.
Click here to find 50hz diesel Generator Set by type (Engine Type).
DCEC CDLO120PSOA Diesel Generator Set
Genset Model: CDLO120PSOA
Engine Model: 6BTAA5.9-G12
Alternator Model：UCI274F
Rate Power: 120kW / 150kVA
Frequency: 50 Hz
DCEC CDLO110PSOA Diesel Generator Set
Genset Model: CDLO110PSOA
Engine Model: 6BTAA5.9-G2
Alternator Model：UCI274E
Rate Power: 110kW / 137.5kVA
Frequency: 50 Hz
DCEC CDLO100PSOA-II Diesel Generator Set
Genset Model: CDLO100PSOA
Engine Model: 6BTAA5.9-G2
Alternator Model：UCI274ES
Rate Power: 100kW / 125kVA
Frequency: 50 Hz
DCEC CDLO90PSOA Diesel Generator Set
Genset Model: CDLO90PSOA
Engine Model: 6BTA5.9-G2
Alternator Model：UCI274D
Rate Power: 90kW / 113kVA
Frequency: 50 Hz
DCEC CDLO80PSOA-III Diesel Generator Set
Genset Model: CDLO80PSOA
Engine Model: 6BT5.9-G2
Alternator Model：UCI274C
Rate Power: 80kW / 100kVA
Frequency: 50 Hz
DCEC CDLO80PSOA-II Diesel Generator Set
Genset Model: CDLO80PSOA
Engine Model: 6BT5.9-G2
Alternator Model：UCI274C
Rate Power: 80kW / 100kVA
Frequency: 50 Hz
DCEC CDLO72PSOA-II Diesel Generator Set
Genset Model: CDLO72PSOA
Engine Model: 6BT5.9-G2
Alternator Model：UCI274C
Rate Power: 72kW / 90kVA
Frequency: 50 Hz
DCEC CDLO68PSOA-II Diesel Generator Set
Genset Model: CDLO68PSOA
Engine Model: 6BT5.9-G2
Alternator Model：UCI224G
Rate Power: 68kW / 85kVA
Frequency: 50 Hz
DCEC CDLO80PSOA-I Diesel Generator Set
Genset Model: CDLO80PSOA
Engine Model: 6BT5.9-G1
Alternator Model：UCI274C
Rate Power: 80kW / 100kVA
Frequency: 50 Hz
DCEC CDLO72PSOA-I Diesel Generator Set
Genset Model: CDLO72PSOA
Engine Model: 6BT5.9-G1
Alternator Model：UCI274C
Rate Power: 72kW / 90kVA
Frequency: 50 Hz
DCEC CDLO68PSOA-I Diesel Generator Set
Genset Model: CDLO68PSOA
Engine Model: 6BT5.9-G1
Alternator Model：UCI224G
Rate Power: 68kW / 86kVA
Frequency: 50 Hz
DCEC 50Hz CDLO50PSOA Industrial Generator Set
Prime Power：92 kW/ 1500 RPM
Engine Model：6BT5.9-G1
Engine Rated Power: 50 kW
Alternator Brand：Stamford
Alternator Model：UCI224F
DCEC 50Hz CDLO75PSOA Industrial Generator Set
Prime Power：90 kW / 1500 RPM
Engine Model：6BT5.9-G2
Engine Rated Power: 75 kW
Alternator Brand：Stamford
Alternator Model：UCI274C
DCEC 50Hz CDLO100PSOA-I Industrial Generator Set
Prime Power：100 kW / 1500 RPM
Engine Model：6BTA5.9-G2
Engine Rated Power: 100 kW
Alternator Brand：Stamford
Alternator Model：UCI274D
