DCEC 50Hz 4BT3.9 Diesel Generator Set
Sinogen Series diesel generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by DCEC 4BT3.9 series diesel engine, comes with 50-degree radiator, Match with Stamford, Marathon or Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 50 Hz of Sinogen Series diesel generator set (1500 RPM) form is 16-72 kW.
Sinogen Series diesel generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
General Specifications of 4BT3.9 Series
| Engine Type: | In-Line,4 Cylinders |
| Displacement(L): | 3.9 |
| Prime Power(kw): | 16 – 72 |
| Standby Power(kw): | 17.6 – 97 |
| Engine Speed: |
1500 r/min |
| Generator Frequency: | 50 Hz |
| Bore * Stroke: | 102 mm * 120 mm |
Generator Model |
Prime Power |
Engine Model |
Generator Model |
Prime Power |
Engine Model |
|||
| CDLO30PSOA | 30 kW / 1500 RPM | 4BT3.9-G1 | CDLO16PSOA | 16 kW / 1500 RPM | 4B3.9-G11 | |||
| CDLO20PSOA-I | 20 kW / 1500 RPM | 4B3.9-G12 | CDLO22PSOA-I | 22 kW / 1500 RPM | 4B3.9-G12 | |||
| CDLO24PSOA | 24 kW / 1500 RPM | 4B3.9-G12 | CDLO20PSOA-II | 20 kW / 1500 RPM | 4B3.9-G1 | |||
| CDLO22PSOA-II | 22 kW / 1500 RPM | 4B3.9-G1 | CDLO20PSOA-III | 20 kW / 1500 RPM | 4B3.9-G2 | |||
| CDLO22PSOA-III | 22 kW / 1500 RPM | 4B3.9-G2 | CDLO32PSOA-I | 32 kW / 1500 RPM | 4BT3.9-G1 | |||
| CDLO32PSOA-II | 32 kW / 1500 RPM | 4BT3.9-G2 | CDLO40PSOA | 40 kW / 1500 RPM | 4BTA3.9-G2 | |||
| CDLO45PSOA | 45 kW / 1500 RPM | 4BTA3.9-G2 | CDLO48PSOA-I | 48 kW / 1500 RPM | 4BTA3.9-G2 | |||
| CDLO48PSOA-II | 48 kW / 1500 RPM | 4BTA3.9-G11 | CDLO58PSOA | 58 kW / 1500 RPM | 4BTA3.9-G11 | |||
| CDLO64PSOA | 64 kW / 1500 RPM | 4BTA3.9-G11 | CDLO72PSOA | 72 kW / 1500 RPM | 4BTA3.9-G13 | |||
| ——END—— | ||||||||
DCEC 4BT3.9 Series Diesel Generator Set
This is the list of all series of DCEC 4BT3.9 Series Diesel Generator Set.
Click here to find 50hz diesel Generator Set by type (Engine Type).
DCEC CDLO72PSOA Diesel Generator Set
Genset Model: CDLO72PSOA
Engine Model: 4BTA3.9-G13
Alternator Model：UCI274C
Rate Power: 72kW / 90kVA
Frequency: 50 Hz
DCEC CDLO64PSOA Diesel Generator Set
Genset Model: CDLO64PSOA
Engine Model: 4BTA3.9-G11
Alternator Model：UCI224G
Rate Power: 64kW / 80kVA
Frequency: 50 Hz
DCEC CDLO58PSOA Diesel Generator Set
Genset Model: CDLO58PSOA
Engine Model: 4BTA3.9-G11
Alternator Model：UCI224F
Rate Power: 58kW / 72.5kVA
Frequency: 50 Hz
DCEC CDLO48PSOA-II Diesel Generator Set
Genset Model: CDLO48PSOA
Engine Model: 4BTA3.9-G11
Alternator Model：UCI224E
Rate Power: 48kW / 60kVA
Frequency: 50 Hz
DCEC CDLO48PSOA-I Diesel Generator Set
Genset Model: CDLO48PSOA
Engine Model: 4BTA3.9-G2
Alternator Model：UCI224E
Rate Power: 48kW / 60kVA
Frequency: 50 Hz
DCEC CDLO45PSOA Diesel Generator Set
Genset Model: CDLO45PSOA
Engine Model: 4BTA3.9-G2
Alternator Model：UCI224E
Rate Power: 45kW / 56.25kVA
Frequency: 50 Hz
DCEC CDLO40PSOA Diesel Generator Set
Genset Model: CDLO40PSOA
Engine Model: 4BTA3.9-G2
Alternator Model：UCI224D
Rate Power: 40kW / 50kVA
Frequency: 50 Hz
DCEC CDLO32PSOA-II Diesel Generator Set
Genset Model: CDLO32PSOA
Engine Model: 4BT3.9-G2
Alternator Model：PI144J
Rate Power: 32kW / 40kVA
Frequency: 50 Hz
DCEC CDLO32PSOA-I Diesel Generator Set
Genset Model: CDLO32PSOA
Engine Model: 4BT3.9-G1
Alternator Model：PI144J
Rate Power: 32kW / 40kVA
Frequency: 50 Hz
DCEC CDLO22PSOA-III Diesel Generator Set
Genset Model: CDLO22PSOA
Engine Model: 4B3.9-G2
Alternator Model：PI144F
Rate Power: 22kW / 27.5kVA
Frequency: 50 Hz
DCEC CDLO20PSOA-III Diesel Generator Set
Genset Model: CDLO20PSOA
Engine Model: 4B3.9-G2
Alternator Model：PI144E
Rate Power: 20kW / 25kVA
Frequency: 50 Hz
DCEC CDLO22PSOA-II Diesel Generator Set
Genset Model: CDLO22PSOA
Engine Model: 4B3.9-G1
Alternator Model：PI144F
Rate Power: 22kW / 27.5kVA
Frequency: 50 Hz
DCEC CDLO20PSOA-II Diesel Generator Set
Genset Model: CDLO20PSOA
Engine Model: 4B3.9-G1
Alternator Model：PI144E
Rate Power: 20kW / 25kVA
Frequency: 50 Hz
DCEC CDLO24PSOA Diesel Generator Set
Genset Model: CDLO24PSOA
Engine Model: 4B3.9-G12
Alternator Model：PI144G
Rate Power: 24kW / 30kVA
Frequency: 50 Hz
DCEC CDLO22PSOA-I Diesel Generator Set
Genset Model: CDLO22PSOA
Engine Model: 4B3.9-G12
Alternator Model：PI144f
Rate Power: 22kW / 27.5kVA
Frequency: 50 Hz
DCEC CDLO20PSOA-I Diesel Generator Set
Genset Model: CDLO20PSOA
Engine Model: 4B3.9-G12
Alternator Model：PI144E
Rate Power: 20kW / 25kVA
Frequency: 50 Hz
DCEC CDLO16PSOA Diesel Generator Set
Genset Model: CDLO16PSOA
Engine Model: 4B3.9-G11
Alternator Model：PI144D
Rate Power: 16kW / 20kVA
Frequency: 50 Hz
DCEC 50Hz CDLO30PSOA Industrial Generator Set
Prime Power：36 kW / 1500 RPM
Engine Model：4BT3.9-G1
Engine Rated Power: 30 kW
Alternator Brand：Stamford
Alternator Model：PI144J
